NUD3112LT1G
Manufacturer:
On Semiconductor
Mfr.Part #:
NUD3112LT1G
Datasheet:
Description:
Gate Drivers SOT-23-3 SMD/SMT Inverting
| Parameter | Value |
|---|---|
| Length | 3.0226 mm |
| Width | 1.397 mm |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 3 |
| Resistance | 900 MΩ |
| Height | 1.016 mm |
| Halogen Free | Halogen Free |
| Radiation Hardening | No |
| REACH SVHC | No SVHC |
| Number of Elements | 1 |
| Current Rating | 500 mA |
| Interface | On/Off |
| Output Current | 400 mA |
| Output Voltage | 14 V |
| Max Power Dissipation | 225 mW |
| Max Supply Voltage | 14 V |
| Power Dissipation | 225 mW |
| Max Output Current | 300 mA |
| Ambient Temperature Range High | 85 °C |
| Continuous Drain Current (ID) | 500 mA |
| Drain to Source Voltage (Vdss) | 14 V |
| Element Configuration | Single |
| Output Configuration | Low Side |
| Number of Outputs | 1 |
| Fall Time | 36 ns |
| Rise Time | 61 ns |
| Number of Drivers | 1 |
| Drain to Source Resistance | 900 mΩ |
| Max Junction Temperature (Tj) | 150 °C |
| Gate to Source Voltage (Vgs) | 6 V |
| Drain to Source Breakdown Voltage (Vds) | 14 V |
| Schedule B | 8542390000 |
| Min Supply Voltage | 3 V |
| RoHS | Compliant |
| Packaging | Reel |
| Configuration | Inverting |
